Factory Hot Sale Aluminum Nitride Ceramic Sheet ALN Disc ain Substrate In Stock

Email: sintyron@xtlceramic.com

Inquiry Now

Products Center

Product Description

Feature

●Very high thermal conductivity

●Excellent electrical insulation

●Low density

●Similar linear expansion coefficient with Si

●Extremely high hardness

Material data sheet

Item	Unit	Aluminium Nitride ceramic/AlN
Linear expansion coefficient	RT-400℃,10-6	4.4
Bulk density	g/cm3	3.2
Thermal conductivity	20 ℃,W/m.k	≥170
Flexural strength	Mpa	≥330
Bulk resistance	Ω.cm	≥1014
Dielectric strength	KV/mm	≥15
Dissipation factor	1 MHz	3 x 10-4
Dielectric constant	1 MHz	9.0

Specification

Standard Thickness	0.385mm 0.5mm 0.635mm 0.8mm 1.0mm
density	3.2g/cm3
Thermal Conductivity (at 20℃)	≥170W/mk
Color	Light grey
Material	Aluminum nitride
Tolerance	+/- 0.1mm
Roughness	Ra 0.2um - 0.6um
size	Customized
Surface	polishing,grinding
Feature	High thermal conductivity

Packing & Delivery

High Thermal Conductivity aln aluminum nitride ceramic insert crucible's standard package:
export carton with bubble film and foam.

Company Profile

Liling Xingtailong is a modern enterprise management company, who devote themselves to the service of product research and development, construction and maintenance. Our company has a long history. We own the advanced equipment, a young, energetic, proficient and experienced team of professionals which with leading technology strength, excellent operational management and high-quality services what made us be recognized by customers of the chemical, petroleum, electric power, metallurgy, building material, aerospace, machinery and other industries. Main product from our factory is crucibles for melting gold,ceramic capacitor,catalytic converter,acid resistant brick,ceramic fiber board,ceramic nozzle,ceramic disc,silicon carbide crucibles,alumina tube,honeycomb ceramic,transformer bushing,ceramic substrate,alumina ball and so on.

FAQ

Why us?
* Professional manufacturer since 1997.
* Strict quality control on production process and tolerance.
* Free samples available
* Customized production based on your drawing or specification
* On-time delivery and reliable support and service
* Inventory available for quick shipment
* We keep confidentiality of all the drawings and business information between us.

Are you a trading company or a manufacturer?
* We are a manufaturer.

Can you provide the free samples?
* Yes,we can offer free sample if we have it in stock,but the courier fee is to be collected.

Do you accept customized production based our specification?
* Yes,we offer OEM and ODM service. Just send us your drawing if you have it. If you don’t have a drawing, just tell us your idea,
we will work out the drawing for you.

What's the delivery time?
* 7 working days for standard products 30 days for customized products.

What is the MOQ?
* No limit to the quantity. We can offer the best proposal and solutions according to your condition.

What is the payment terms you accept?
* T/T,LC,Western Union,moneygram are acceptable.

How to deal with the faulty?
* Firstly, Our product are produced in strict quality control system and the defective rate will be less than 2%.
If there are problems with the product, we will provide free replacement.
