SINTYRON 95% 99% al2o3 alumina ceramic laser cavity reflector


High-purity alumina ceramic laser cavity reflector offering exceptional thermal stability and >99% reflectivity for precision laser systems.

Email: sintyron@xtlceramic.com

Inquiry Now

Products Center


SINTYRON 95% 99% al2o3 alumina ceramic laser cavity reflector

Product description:

Product Overview

Ultra-stable alumina ceramic reflectors for high-power laser systems, offering exceptional thermal

 management and reflectivity >99% at 1064nm wavelength. Ideal for industrial cutting/welding lasers,

 medical devices, and scientific research applications.



Material Grade

99.6% Pure Al₂O₃ Ceramic

Fully dense microstructure (≥3.92 g/cm³)



Performance Advantages

Reflectivity: 99.2-99.8% @1064nm (customizable coatings available)

Thermal Conductivity: 28-32 W/m·K

Coefficient of Thermal Expansion: 7.2-8.4 ×10⁻⁶/°C (20-800°C)

Surface Roughness: Ra ≤0.05μm (mirror polish option)



Robust Design

Damage Threshold: >10 J/cm² (10ns pulse, 1064nm)

Operating Temperature: -60°C to +1500°C

Vacuum compatible (10⁻⁶ Torr)



Technical Specifications

ParameterValue
Standard Diameter10mm-150mm (±0.01mm tolerance)
Thickness3mm-20mm (±0.005mm)
Flatnessλ/10 @632.8nm
Coating OptionsHR@1064nm, AR@532nm, Gold, Dielectric
MountingThreaded, Flanged, Unmounted



































Application:

Industrial Lasers: CO₂/YAG laser resonators

Medical Equipment: Surgical laser delivery systems

Aerospace: LIDAR and laser communication

Research: Ultrafast laser cavities, spectroscopy
