China supplier Alumina Nitride AIN Ceramic substrate Plate with 0.2-30mm thickness

Alumina Nitride AlN Substrate Ceramic plate Part

Email: sintyron@xtlceramic.com

Inquiry Now

Products Center

China supplier Alumina Nitride AIN Ceramic substrate Plate with 0.2-30mm thickness

alumina nitride ain ceramic substrate plate have gained significant popularity in various industries due to their exceptional properties. With high thermal conductivity, these plates can effectively dissipate heat, making them ideal for applications where heat management is crucial. This characteristic is particularly beneficial in high - power electronic devices, as it helps to maintain the stability and reliability of the components, preventing overheating and potential failures.

In addition to excellent thermal performance, our AlN ceramic substrate plates also offer outstanding electrical insulation. The high dielectric strength ensures that there is minimal electrical interference, allowing for the smooth operation of electronic circuits. This makes them a preferred choice for advanced electronic systems, including integrated circuits, power modules, and high - frequency devices.

The mechanical properties of our alumina nitride ain ceramic substrate plate are also remarkable. They have high hardness and good wear resistance, which means they can withstand harsh operating conditions and mechanical stresses. This durability extends the service life of the devices using these plates, reducing the need for frequent replacements and ultimately saving costs.

,_01

Performance for Industrial Ceramic

		Alumina Nitride (AlN)
Characteristics	Item	AlN180	AlN200	AlN220	Unit
Mechanical Characteristics	Colour	Gray	Gray	Beige
	Density	3.3	3.3	3.28	g/cm³
	Flexural Strength	≥350	≥350	≥350	MPa
	Compressive Strength	2500	2500	-	MPa
	Elastic Modulus	320	320	320	GPa
	Vickers Hardness (Load 500g)	10	9.5	9	HV0.5
Thermal Characteristics	Coefficient of Line Thermal Expansion	4.8	4.6	4.5	10^-6K^-1
Thermal Characteristics	Thermal Conductivity(20℃)	180	200	220	W/m·K
Electrical Characteristics	Volume Resistance at 20°C	>10¹⁴	>10¹⁴	>10¹³	cm
	Dielectric Strength	≥15	≥15	≥15	KV/mm
	Dielectric Constant (1MHz)	9	8.8	8.6	εr
	Loss Tangent	5	5	3	10^-4

,_04

Related Products

FAQ

Why us?
* Professional manufacturer since 1997.
* Strict quality control on production process and tolerance.
* Free samples available
* Customized production based on your drawing or specification
* On-time delivery and reliable support and service
* Inventory available for quick shipment
* We keep confidentiality of all the drawings and business information between us.
Are you a trading company or a manufacturer?
* We are a manufaturer.
Can you provide the free samples?
* Yes,we can offer free sample if we have it in stock,but the courier fee is to be collected.
Do you accept customized production based our specification?
* Yes,we offer OEM and ODM service. Just send us your drawing if you have it. If you don’t have a drawing, just tell us your idea, we will work out the drawing for you.

What's the delivery time?
* 7 working days for standard products 30 days for customized products.
What is the MOQ?
* No limit to the quantity. We can offer the best proposal and solutions according to your condition.
What is the payment terms you accept?
* T/T,LC,Western Union,moneygram are acceptable.
How to deal with the faulty?
* Firstly, Our product are produced in strict quality control system and the defective rate will be less than 2%.
If there are problems with the product, we will provide free replacement.
